package:DIP-8
MICROCHIP
ER59256/P
• Low cost
• 16 x 16 serial EEPROM
• Single +5V only operation
• Binary addressing
• Word and chip erasable
• Unlimited read accesses
• Fully TTL compatible inputs and outputs
• ESD Protection: Inputs are designed to meet 1.0KV per test method 3015.1, MIL-STD 883
• Highly reliable N-Channel SNOS technology
• Designed for 10 year data retention after 10,000 erase/write cycles per word.
• Power on/off data protection circuitry
• Available for extended temperature ranges:
— Commercial: O’C to +70*C
— Industrial: -40’C to +85’C
The ER59256 Is a low cost, serial EEPROM manufac-tured In Microchip’s highly reliable SNOS technology. The key featuresof this device are its +5V only operation and microcomputer compatible architecture. Six 9-bit instructions can be executed. See Table 1. The instruc-tion format has a logical “1” as a start bit, four bits as an opcode, and four bits of address.
