LM124J

LM124J

• package: DIP-14
• Brand :NATIONAL
• 2-kV ESD Protection for:
• LM224K, LM224KA
• LM324K, LM324KA
• LM2902K, LM2902KV, LM2902KAV
• Wide Supply Ranges
• SingleSupply…3Vto32V
• (26 V for LM2902)
• DualSupplies…+1.5Vto+16V
• (+13 V for LM2902)
• Low Supply-Current Drain Independent of
• Supply Voltage . . . 0.8 mA Typ
• Common-Mode Input Voltage Range Includes Ground, Allowing Direct Sensing Near Ground
• Low Input Bias and Offset Parameters − Input Offset Voltage . . . 3 mV Typ
• A Versions . . . 2 mV Typ
• Input Offset Current . . . 2 nA Typ − InputBiasCurrent…20nATyp
• A Versions . . . 15 nA Typ
• Differential Input Voltage Range Equal to Maximum-Rated Supply Voltage . . . 32 V  (26 V for LM2902)
• Open-Loop Differential Voltage Amplification . . . 100 V/mV Typ
• Internal Frequency Compensation
