The DAC0808 series is an 8-bit monolithic digital-to-analog converter (DAC) featuring a full scale output current settling time of 150 ns while dissipating only 33 mW with g5V sup- plies No reference current (IREF) trimming is required for most applications since the full scale output current is typi- cally g1 LSB of 255 IREF 256 Relative accuracies of bet- ter than g019% assure 8-bit monotonicity and linearity while zero level output current of less than 4 mA provides 8-bit zero accuracy for IREFt2 mA The power supply cur- rents of the DAC0808 series are independent of bit codes and exhibits essentially constant device characteristics over the entire supply voltage range
The DAC0808 will interface directly with popular TTL DTL or CMOS logic levels and is a direct replacement for the
MC1508 MC1408 For higher speed applications see DAC0800 data sheet
