• Continuous Short-Circuit Protection
• Wide Common-Mode and Differential Voltage Ranges
• No Frequency Compensation Required
• Low Power Consumption
• No Latch-Up
• Unity-Gain Bandwidth … 3 MHz Typ
• Gain and Phase Match Between Amplifiers
• Designed To Be Interchangeable With Raytheon RC4136, RM4136, and RV4136
• Low Noise … 8 nVA/Hz Typ at 1 kHz
The RC4136, RM4136, and RV4136 are quad general-purpose operational amplifiers, with each amplifier electrically similar to the iiA741, except that offset null capability is not provided. The high common-mode input voltage range and the absence of latch-up make these amplifiers ideal for voltage-follower applications. The devices are short-circuit protected and the internal frequency compensation ensures stability without external components. The RC4136 is characterized for operation from 0°C to 70°C, the RM4136 is characterized for operation over the full military temperature range of —55°C to 125°C, and the RV4136 is characterized for operation from —40°C to 85°C.
